PRODUCT DESCRIPTION
1.The length can be customized between 2,200~2,800mm.
2.The column is a six-sided cylinder, designed for gas, strong electric and weak electric separation chamber.
TECHNICAL PARAMETERS
| Max. load | 270kg |
| Medical gas outlets standards | optional British, German, French, Metric, Ohmeda, DISS, Chemetron, Purit-Bennett standards |
| Beam length | 2,800mm(optional different length) |
| Column movement | manual(optional electrical control) |
| Braking system | Mechanical braking(optional air pneumatic or electromagnetic braking) |
STANDARD CONFIGURATION
| Gas outlet | O2*2, Air*2, Vac*2 |
| Electrical socket | 12 pcs |
| Equipotential earthing terminal port | 4 pcs |
| Network interface | 2 pcs |
| Phone interface | 2 pcs |
| Instrument shelves(height adjusted) | 4 pcs |
| Self priming drawer | 2 pcs |
| Basket | 1 pcs |
| I.V Pole(height adjustable) | 1 pcs |
| LED light | 2 pcs |
OPTIONAL CONFIGURATION, ACCESSORIES AND SERVICE
